Hi-speed Organosilicone spray surfactant

SPECIFICATION

1: Mode of action of HI-SPEED Spray surfactant:

Hi-speed Srapy surfactant makes the water surface tension lower down to the 20.5mN/m at the concentration of 0.1%(wt). After the mixture with the pesticide solution at the certain proportion, It can lower the contact angle between the spray and foliage,which can enlarge the coverage of the spray. Furthermore, it can make the pesticide absorbed through the stomatal leaves, which is extremely effective for improving efficacy,reducing amount of pesticide,saving cost,reducing environmental pollution caused by pesticides.

2: Typical properties HI-SPEED Spray surfactant:

Hi-speed(Organosilicone surfactant /spreading&wetting,penetrating agent) Basic Characteristics:

Appearance	Colourless to light amber liquid
Active content %	100%
Composition	Silicone Polyether
Viscosity (at 25℃)	15-45(cst)
Surface Tension (0.1% AS)(at 25℃)	19-20mN/m
Density	1.01-1.02g/cm3
Cloud point （0.1% AS）	<10℃
PH	6.0-8.0

Osmotic Force Testing Result（Canvas Method）

Product	Hi-Speed (Organosilicon surfactant/spreading & wetting,penetrating agent for agriculture)
×1000，s	4
×2000，s	5
×5000，s	6

Spreadability Testing Result

Product	Hi-Speed (Organosilicone sufactant/spreading & wetting,penetrating agent for agriculture)
Contact Angle，°	<5
Spread Area，mm2	6082

The Surface Tension of Various Surfactants

Product name of Surfactant	Mass Fraction in Water	Surface Tension（25℃）mN/m	Spread Diameter in 30S (mm)
XP-S	5%	32.5	5
601	5%	40.5	4
JFC	5%	31.0	7
Hi-Speed	0.1%	20.1	41

3: Applications:

(1): Hi-speed is a super spreading and penetrating agent can be used in formulate or as a tank mix.

(2): Hi-speed, use as a component of 0.5-8% in agrochemical formulations.
Proposing regulation of pesticide formulations PH value of 6-8.

(3): Hi-speed, use as a tank mix adjuvant, As usual, add 50ml Hi-speed to 200Liter spray solution (4000-times dilution).

Application	Typical Use Rate by tank mixing
Plant Growth Regulators	0.025-0.05%
Herbicide	0.025-0.15%
Insecticide	0.025-0.1%
Fungicide	0.015-0.05%
Fertilizers and trace elements	0.015-0.1%

Hi-speed wetting properties are useful in various industrial applications e.g. Inks & coatings, Agriculture ,
leather,textile and any other applications where strong surface tension reductions,wetting and spreading are desired.

Applying	Functions and benefits
Foliar Spraying	Increase the ability of wettability, adhesion and spreadability of agrochemicals on the plants and insects.
Adjuvant for promoting absorption	Cause the surface tension of agrochemicals solution lower than the critical value of plant leaf surface wetness (about 25mN/m), so it can promote the agrochemicals enter into epidermis to increase the absorption of agrochemicals and increase utilization rate about 20%-30%.
Activator	The excellent surface activity of Hi-Speed can soak acarid and insects easily and cause suffocation and disturb their main physiological process.

4. Hi-Speed Practical application cases and data on agriculture:

Mix Hi-Speed with Foliar fertilizers:

Foliar fertilizer is very important to supply various nutrition to plants, such as N, P, K and trace elements.
When mix Hi-Speed with foliar fertilizers to spray, it will promote absorption of nutrition, increase utilization of foliar fertilizer,
save cost.

Field trials of Hi-Speed at Mix 5ml with 20L water in tank and then spray

Effect of “Hi-Speed” on Spring wheat aphid (Heilongjiang Province, China, 2017)

Treatment Active Ingredient (g·hm-2)		1 day later		3 days later		7 days later		14 days later
Treatment Active Ingredient (g·hm-2)		Control efficiency (%)	Significant difference	Control efficiency (%)	Significant difference	control efficiency (%)	significant difference	control efficiency (%)	significant difference
Chlorpyrifos (Added Hi-Speed)	300	53.74	Ed	80.89	EFe	82.95	Gg	77.42	GHfg
	450	59.63	BCDbc	85.69	CDbc	87.94	BCDEcde	85.18	CDEd
	600	67.16	Aa	90.81	Aa	92.36	Aa	88.27	ABCabc
Chlorpyrifos (No Hi-Speed)	300	46.11	Fe	75.93	Gf	79.27	Hh	75.89	Hg
	450	54.12	DEd	81.27	EFe	83.22	FGg	80.14	FGef
	600	59.13	BCDb	85.76	CDbcd	87.09	CDEdef	83.67	DEd
CK	-	0.00	——	0.00	——	0.00	——	0.00	——

Field trials of Hi-Speed at Mix 5ml with 20L water in tank

Effect of “Hi-Speed” on rice leaf folder (Ningbo, Zhejiang Provice, China, 2010)

Treatment Active Ingredient (g·hm-2)		10 days later		20 days later
Treatment Active Ingredient (g·hm-2)		control efficiency (%)	significant difference	control efficiency (%)	significant difference
Chlorpyrifos (Add Hi-Speed)	300	76.17	CDde	74.53	EFd
	450	81.85	ABabc	77.65	CDEFcd
	600	86.24	Aa	82.44	ABab
Chlorpyrifos (No Hi-Speed)	300	67.19	Ef	69.78	Ge
	450	74.72	De	73.62	FGd
	600	78.07	BCDcde	78.49	BCDEFbc
CK	-	0.00	——	0.00	——

SAFETY

Before handling, read the Material Safety Data Sheet and container label for safe use, physical and health hazard information.

5. STORAGE AND SHELF LIFE

After sealing packaging products stored in a cool, dry place , Hi-speed has a shelf life of 36 months from date of manufacture.

6.PACKAGING

Hi-speed is available in 200L drum and 1000L IBC or as per customers’ requirement
